Sabvoton Controller SVMC72100 SVMC-M Serial Model are programmable 100A DC ebike controller works with high efficiency, less noise, and lower energy consumption, which makes your electric scooter or electric bicycle more comfortable and easier to control. Ebike Controller, electric bike motor controller, ebike motor controller, 72v electric bicycle controller.
• FOC 180 hall sine wave controller applied to BLDC or PMSM.
• Easy connect
• Soft start and no noise
• Programmable 72v electric bicycle controller by PC and Phone
• EBS & Regenerative function support
• Flux Weakening function support
• OEM & ODM Service support, ncyclebike Controller
OVERVIEW
- Generally SPEC -
MQ(Sabvoton) brsuhless dc controller- SVMC72100-M V2
1) Model: SVMC72100-M V2 risun motor Controller
2) Available Battery Voltage: 48V-72V
3) Available Motor Power: 2KW - 3KW
4) Peak DC Current: 100A
5) Phase Peak Current: 250A
6) Working Communication: Hall Sensor
7) Installation Size: 275mm * 122mm * 63 mm
8) Weight: 2.2kg
9) Defaut Throttle Working Voltage: 0V - 5V
10) Mosfets Detail: 24FET
11) Case Material: Aluminum
12) Controller Design: 100A DC ebike controller,
13) Support Programmable by PC & Phone
14) Certification: CE, CCC
- Controller Design -
Electric bike motor controller, 100A sine wave controller, Programmable, With Hall Plug, 120 degree Phase Angle.
Functions: Hall, 0-5V Throttle, PAS, Speed Limit, Low Brake, Display, Reverse, Anti-Theft, Program Port.
