Sabvoton Controller SVMC Serial Model are programmable bldc controller works with high efficiency, less noise, and lower energy consumption, which makes your electric scooter or electric bicycle more comfortable and easier to control. Our designed worked well as sabvoton controller SVMC72200, 200A electric bicycle controller, BLDC SVMC72200, electric scooter motor controller, electric bicycle 200A powerful controller.
•FOC 180 sinusoidal drive controller applied to BLDCM or PMSM.
•Easy connect
•Soft start and no noise
•Programmable by PC and Phone
•EBS & Regenerative function support
•Flux Weakening function support
•OEM & ODM Service support
OVERVIEW
- Generally SPEC -
MQ(Sabvoton) sabvoton controller SVMC72200
1) Model: SVMC72200
2) Available Battery Voltage: 48V-72V
3) Available Motor Power: 4KW - 5KW
4) Peak DC Current: 200A
5) Phase Peak Current: 450A
6) Working Communication: Hall Sensor
7) Installation Size: 283mm * 147mm * 62mm
8) Weight: 2.5 kgs
9) Defaut Throttle Working Voltage: 0V - 5V
10) Mosfets Detail: 30 FET
11) Case Material: Aluminum
12) Controller Design: Electric Bicycle 200A Powerful Controller, 200A Electric Bicycle Controller
13) Support Programmable by PC & Phone
14) Certification: CE, CCC
- Controller Design -
Brushless DC, Sine Wave, Programmable, electric scooter motor controller, With Hall Plug, 120 degree Phase Angle.
Functions: Hall, Ignition, Throttle, 0-5V e-brake, High Brake, Low Brake, Three Speed, Reverse, Hall speed USB Port.
