Sabvoton Controller ML Serial Model are programmable sine wave motor controller works with high efficiency, less noise, and lower energy consumption, which makes your electric scooter or electric bicycle more comfortable and easier to control. Our designed worked well for BLDC hall sensor motor, electric scooter controller, sine wave controller, bldc gearless controller,electric scooter controller
.
• FOC 180 sine wave controller applied to BLDC motor or PMSM.
• Easy connect
• Soft start and no noise
• Programmable DC Controller by PC
• EBS & Regenerative function support
• Flux Weakening function support
• OEM & ODM Service support
OVERVIEW
- Generally SPEC -
MQ(Sabvoton) electric scooter controller - ML7260
1) Model ML7260
2) Available Battery Voltage 48V-72V
3) Available Motor Power 1000-1500W
4) Phase Peak Current 150A
5) DC Current 60A
6) Working Communication Hall Sensor
7) Instaliing Size 224mm * 111mm * 51 mm
8) Weight 1.6 kgs
9) Defaut Throttle Working Voltage 0V - 5V
10) Mosfets Detail 18 FET
11) Case Material / Color Aluminum / Gray-Black
12) Controller Design Sine Wave Brushless DC Motor Controller
13) Support Programmable by PC
- Controller Design -
BLDC gearless controller, Sine Wave, Programmable, With Hall Plug, 120 degree Phase Angle.
Functions: Hall, Ignition, Throttle, EBS, High Brake, Low Brake, Three Speed, Speed Limit, Reverse, Hall speed, Phase Speed, Alarm, Cruise.
#sabvoton controller#sine wave motor controller#BLDC gearless controller#electric scooter controller#
