Sabvoton Controller SVMC-M Serial Model are programmable Powerful 4kw bicycle controller works with high efficiency, less noise, and lower energy consumption, which makes your electric scooter or electric bicycle more comfortable and easier to control. Our designed worked well as sabvoton SVMC72200 Controller,Powerful 4kw bicycle controller,200A sine wave controller,QS 4kw bike motor controller.ebike controller,ncyclebike Controller.


• FOC 180 QS 4kw bike motor controller applied to BLDC or PMSM.
• Easy connect
• Soft start and no noise
• Programmable DC Controller by PC and Phone
• EBS & Regenerative function support
• Flux Weakening function support
• OEM & ODM Service support

Contact Us


- Generally SPEC -

MQ(Sabvoton) sabvoton SVMC72200 Controller- SVMC72200-M V2
1) Model: SVMC72200-M V2 ncyclebik Controller
2) Available Battery Voltage: 48V-72V
3) Available Motor Power: 4KW - 5KW
4) Peak
DC Current: 200A
Phase Peak Current: 450A
6) Working Communication: Hall Sensor
7) Installation Size: 308mm * 122mm * 63 mm
8) Weight: 2.5kg
9) Defaut Throttle Working Voltage: 0V - 5V
10) Mosfets Detail: 36FET
11) Case Material: Aluminum
12) Controller Design: Powerful 4kw bicycle controller,ebike controller
13) Support Programmable by PC & Phone
14) Certification: CE, CCC

- Controller Design -

sabvoton SVMC72200 Controller,200A sine wave controller, Programmable, With Hall Plug, 120 degree Phase Angle.

Functions: Hall, 0-5V Throttle, PAS, Speed Limit, Low Brake, Display, Reverse, Anti-Theft, Program Port.

#sabvoton SVMC72200 Controller#Powerful 4kw bicycle controller#200A sine wave controller#QS 4kw bike motor controller#ebike controller#ncyclebike Controller
